EquationOfState Class Reference

Base class for equation of state. More...

#include <equation_of_state.hpp>

Inheritance diagram for EquationOfState:

Public Member Functions
virtual double	dp2e (double d, double p, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the thermal energy per unit mass. More...
virtual double	de2p (double d, double e, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the pressure. More...
virtual double	de2c (double d, double e, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the speed of sound. More...
virtual double	dp2c (double d, double p, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the speed of sound. More...
virtual double	dp2s (double d, double p, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the entropy per unit mass. More...
virtual double	sd2p (double s, double d, tvector const &tracers=tvector(), vector< string > const &tracernames=vector< string >()) const =0
	Calculates the pressure from the netropy. More...

Detailed Description

Base class for equation of state.

Definition at line 20 of file equation_of_state.hpp.

Member Function Documentation

de2c()

virtual double EquationOfState::de2c ( double  d, double  e, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the speed of sound.

Parameters

d	Density
e	Specific thermal energy
tracers	Tracers
tracernames	The names of the tracers

Returns

Speed of sound

Implemented in IdealGas, and IdealGas_SR.

de2p()

virtual double EquationOfState::de2p ( double  d, double  e, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the pressure.

Parameters

d	Density
e	Specific thermal energy
tracers	Tracers
tracernames	The names of the tracers

Returns

Presusre

Implemented in IdealGas, and IdealGas_SR.

Here is the caller graph for this function:

dp2c()

virtual double EquationOfState::dp2c ( double  d, double  p, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the speed of sound.

Parameters

d	Density
p	Pressure
tracers	Tracers
tracernames	The names of the tracers

Returns

Speed of sound

Implemented in IdealGas, and IdealGas_SR.

Here is the caller graph for this function:

dp2e()

virtual double EquationOfState::dp2e ( double  d, double  p, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the thermal energy per unit mass.

Parameters

d	Density
p	Pressure
tracers	Tracers
tracernames	The names of the tracers

Returns

Thermal energy per unit mass

Implemented in IdealGas, and IdealGas_SR.

Here is the caller graph for this function:

dp2s()

virtual double EquationOfState::dp2s ( double  d, double  p, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the entropy per unit mass.

Parameters

d	Density
p	Pressure
tracers	Tracers
tracernames	The names of the tracers

Returns

Entropy

Implemented in IdealGas, and IdealGas_SR.

Here is the caller graph for this function:

sd2p()

virtual double EquationOfState::sd2p ( double  s, double  d, tvector const &  tracers = tvector(), vector< string > const &  tracernames = vector< string >()  ) const

pure virtual

Calculates the pressure from the netropy.

Parameters

s	Entropy
d	Density
tracers	Tracers
tracernames	The names of the tracers

Returns

Entropy

Implemented in IdealGas, and IdealGas_SR.

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• source/newtonian/common/equation_of_state.hpp
• source/newtonian/common/equation_of_state.cpp
